To connect two OSPF regular areas without a virtual link, you can use a GRE (Generic Routing Encapsulation) tunnel. Here’s a step-by-step guide:
Why GRE Tunnel?
A GRE tunnel allows you to encapsulate OSPF packets within a GRE header, which can be routed through a non-OSPF area. This approach eliminates the need for a virtual link.
Configuration Steps:
- Create a GRE Tunnel:
- Configure a GRE tunnel between the two routers that connect the two OSPF regular areas.
- Use the
tunnel mode gre ipcommand to create a GRE tunnel interface.
- Configure OSPF on the GRE Tunnel:
- Configure OSPF on the GRE tunnel interface, specifying the area ID and network type.
- Use the
router ospfcommand to enable OSPF on the GRE tunnel interface.
- Configure OSPF on the Physical Interfaces:
- Configure OSPF on the physical interfaces that connect to the GRE tunnel, specifying the area ID and network type.
- Use the
router ospfcommand to enable OSPF on the physical interfaces.
Example Configuration:
Suppose we have two routers, R1 and R2, that connect two OSPF regular areas, Area 1 and Area 2.
R1 Configuration:
interface Tunnel0
tunnel mode gre
ip tunnel source FastEthernet0/0 tunnel destination 192.168.2.2
ip address 10.1.1.1 255.255.255.0
router ospf 1
network 10.1.1.0 0.0.0.255 area 1 interface FastEthernet0/0
ip address 192.168.1.1 255.255.255.0 router ospf 1
network 192.168.1.0 0.0.0.255 area 1
R2 Configuration:
interface Tunnel0
tunnel mode gre ip
tunnel source FastEthernet0/0
tunnel destination 192.168.1.1
ip address 10.2.2.1 255.255.255.0
router ospf 1
network 10.2.2.0 0.0.0.255 area 2
interface FastEthernet0/0
ip address 192.168.2.2 255.255.255.0
router ospf 1
network 192.168.2.0 0.0.0.255 area 2
By using a GRE tunnel, you can connect two OSPF regular areas without a virtual link. This approach provides a flexible and scalable solution for connecting multiple OSPF areas.
